Description
Features of the Trainer
Input Supply
Voltage range : AC 100V – 230V.Frequency Range : 50 – 60Hz.
AF Oscillator:OUTPUT
Sine/SQUARE.
Frequency X1
20Hz to 200Hz.
X10
200Hz to 2KHz.
Amplitude
0-10V (P-P).
CLOCK GENERATOR:CLOCK
CLOCK FREQUENCY VARY WITH FREQUENCY CONTROL POTENTIOMETER.
PULSE
CLOCK PULSE WIDTH VARY WITH PULSE WIDTH CONTROL POTENTIOMETER
1.5 MHZ SYNC PULSE O/P
VARIES FROM1.1MHZ TO1.5MHZ (FREQUENCY CONTROL POTENTIOMETER PROVIDED FOR FINE FREQUENCY ADJUSTMENT)
noise injector
15VAC vary with 1K trimmer provided on the top panel of the trainer using as a noise source.
Housing
It is housed in an elegant metal cabinet(CNC Machine finish)
Dimension
45cm x 45cm x 18cm
Weight
6kgs
This trainer is a glass-epoxy printed circuit board and all the symbols screen-printed on the front panel so that it enables the student to conduct the experiments easily
Accessories:
• 2mm multi coloured moulded patch cords with daisying facility.
• Computer simulated outputs and Step-By-Step detailed instructions are provided with the instruction manual.
• Aliner
