N-10 BCD TO 7-SEGMENT DISPLAY DECODER (COMMON ANODE & COMMON CATHODE TYPES)
N-10 BCD TO 7-SEGMENT DISPLAY DECODER (COMMON ANODE & COMMON CATHODE TYPES) - Image 2

N-10 BCD TO 7-SEGMENT DISPLAY DECODER (COMMON ANODE & COMMON CATHODE TYPES)

Category Special!

🚚 Delivery within 10 days

To study the operation of common anode and common cathode type displays. To study the BCD inputs that are given by logic switches are decoded by the decoder IC. To display the corresponding decimal equivalent outputs.

Add to Quote
Category:

Description

FEATURES OF THE TRAINER:

Built in regulated power supply : +5V/300 mA.

Instruction Manual : Step-By-Step detailed instruction manual.

Dimension : 27cmX 17cm X 10cm

Input Supply : 230V AC/50 Hz mains operated

Housing : Enclosed in an elegant plastic injection moulded cabinet for better viewing & portability.

Weight : 500 Gm.

This trainer is a glass-epoxy printed circuit board and all the symbols screen-printed on the front panel so that it enables the student to conduct the experiments easily.
