FEATURES:
• System works on 230V AC
• Interfacing Hardware and Software with USB to study SCADA operations
• Flow, Level. Cascade and Ratio control
• System controls ON-OFF through PID.
• Closed loop water circulation
• Interfacing Hardware and Software with USB to study SCADA operations
• MODBUS communication
• Mono block pumps of 0.5 HP are used.
• System is frame with wheel arrangement.
• Dimensions: W: 800 mm, Ht: 1450 mm, D: 650 / 450 mm.
RANGE OF EXPERIMENTS:
• cascade control – Level + Flow
• Ratio Control – Flow + Flow
study of SCADA Software
