LDR AS OPTICAL SENSOR

LDR AS OPTICAL SENSOR

Category Special!

🚚 Delivery within 10 days

To study the LDR resistance that changes in proportion to light intensity and corresponding change in the voltage divider output Vout that is given by

VOut = [(Rcal/RLDR) + 1] x Vin

To study the LDR as part of a voltage divider. To study the LDR being used as part of the resistive feedback network of a non-inverting op-amp circuit.

Add to Quote
Category:

Description

FEATURES OF THE TRAINER:

Built in regulated power supply :+15v,-15v/300 mA.

Instruction Manual : Step-By-Step detailed instruction manual.

Dimension : 27cmX 17cm X 10cm

Input Supply : 230V AC/50 Hz mains operated

Housing : Enclosed in an elegant plastic injection molded cabinet for better viewing & portability.

Weight : 500 Gm.

This trainer is a glass-epoxy printed circuit board and all the symbols screen-printed on the front panel so that it enables the student to conduct the experiments easily.
