G-08 TWIN T OSCILLATOR

 3,950.00

TWIN-T OSCILLATOR (OR) NOTCH FILTER notches or attenuates frequency near the oscillator frequency. An op-amp is used as the amplifier in this oscillator. The positive feedback is through the voltage divider to the non-inverting input and the twin-T filter.

Share this product

Share on facebook
Share on twitter
Share on linkedin
Share on pinterest
Share on whatsapp

FEATURES OF THE TRAINER:

Built in regulated power supply :+12V And -12V/300 mA.

Instruction Manual : Step-By-Step detailed instruction manual.

Dimension : 27cmX 17cm X 10cm

Input Supply : 230V AC/50 Hz mains operated

Housing : Enclosed in an elegant plastic injection molded cabinet for better viewing & portability.

Weight : 500 Gm.

This trainer is a glass-epoxy printed circuit board and all the symbols screen-printed on the front panel so that it enables the student to conduct the experiments easily
