FEATURES:
• 7.8″ (640 × 480) 256 COLOURS LCD Display,Backlight & Contrast Adjustable
• Sampling Rate : 10 S/S ~ 250 MS/S
• Record Length : 5 K Sampling Points / Ch.
• Auto Setup for quick setting-up and waveform display
• Upto 5 Auto-Measurements
• Many Waveform storage
• Dual Channel with Probe Attenuation Ratio setup
• Dual Cursor Measurements : ΔV, ΔT & 1 / ΔT
• Standard Sampling / Peak Value Sampling / Average Sampling
• Multilingual menu includes English Menu
• USB Interface (Optional)
• Battery Operation (Optional)
• Rise Time Approx: 17.5ns(*5 MAG: 50ns)
• Vertical Deflection-5 mV /div. ~ 5 V / div
• DC Gain Accuracy-± 5 %
• Vertical Resolution-8 bit Simultaneous sampling
• Sweep Time-5 S ~ 5 nS / div
• Power-AC 100 ~ 240 V (RMS), < 15 W
• Environmental-Working Temp.: 0 ºC ~ 40 ºC, R.H. ≤ 90 %
• Size & Weight -350 × 157 × 120 (mm), Approx. 1 Kg
• Accessories-One Manual, One Mains Cord & Two Probes (1:1/10:1)
• Optional-USB Interface & Battery Operation.
