C-17 CONSTRUCTION OF FAN REGULATOR USING DIAC & TRIAC

The purpose of this experiment is
• To construct a fan regulator circuit using TRIAC.
• The firing angle of TRIAC can be controlled by employing a DIAC circuit.

Share this product

Share on facebook
Share on twitter
Share on linkedin
Share on pinterest
Share on whatsapp

Features of the Trainer
Power Supply :Voltage range: AC 100V – 230V.Frequency Range : 50 – 60Hz.
Housing :
It is mounted in an elegant ABS Plastic cabinet for better viewing and portability.
Dimension : 29cm x 20cm x 11cm
Weight :  1.5kgs
This trainer is a glass-epoxy printed circuit board and all the symbols screen-printed on the front panel so that it enables the student to conduct the experiments easily

Accessories:
• 2mm multi coloured moulded patch cords with daisying facility.
Computer simulated outputs and Step-By-Step detailed instructions are provided with the instruction manual.
